WPRORXSPLIT6 - Indoor Receiver w/WDMX G3/4 & LumenRadio AB CRMX, 6-Way Splitter

Overview
Indoor wireless DMX receiver with a built-in 6-way splitter, supporting W-DMX G3/G4S and LumenRadio CRMX. It has 5-pin XLR in/thru and six 5-pin XLR outputs.

Best for
Receiving wireless DMX and distributing it to several fixture runs from one unit.

Highlights

• Receiver with built-in 6-way splitter
• W-DMX G3/G4S and CRMX compatible
• 5-pin XLR in/thru and 6 x 5-pin XLR outputs
• Truss mounting bracket included

Key Specs

• Part Number: WPRORXSPLIT6
• Brand: Event Lighting
• DMX channels: 512 (1 universe)
• Signal connectors: 5-pin XLR female in/thru; 6 x 5-pin XLR outputs
• Power connector: Powercon in
• IP rating: IP20
• Frequency: 2.4 GHz, AFHSS modulation
• Compatibility: CRMX, W-DMX G3, G4S
• Working range: 500 m (1,640 ft) line of sight
• Antenna: 5 dBi
• DMX latency: under 5 ms
• Universes in coexistence: up to 16
• Dimensions: 5.4 x 4.8 x 3.8 in (137 x 122 x 97 mm)
• Weight: 1.8 lb (0.8 kg)
