MAR-90357703 - VDO Atomic Bold in cardboard

Overview
The VDO Atomic Bold is a full-colour LED blinder, strobe and wash fixture with a dual-layer design: a high-output RGBW beam in front of a pixel-controllable RGB aura backlight. Martin built it for rental, touring and TV lighting, and the combination of beam and aura gives a tungsten-style look. It ships as a single unit in a cardboard carton.

Best for
Concert, corporate and nightclub lighting where a compact, IP65-rated blinder / strobe / eye-candy fixture is needed, alone or in arrays on the VDO Grid Mount System.

Highlights

• Dual-layer design: high-lumen RGBW beam plus 72 individually controllable RGB aura pixels
• 13,000 lumens in boost/strobe mode and 8,000 lumens continuous, with a 12 degree beam
• IP65 rated for indoor use and temporary outdoor use
• Fixtures combine into battens, arrays and custom shapes with the VDO Grid Mount System
• Hybrid PDE power/data connectors allow daisy-chaining
• PAR64-size front accessory holder takes diffusers and barndoors

Key Specs

• Light source: RGBW LED beam (CRI 83 or higher, TLCI 85 or higher) plus 72-pixel RGB aura
• Beam angle: 12 degrees; field angle 26 degrees
• Power: 100-240 V AC, 50/60 Hz; 400 W max, 358 W typical
• Control: DMX, Art-Net, sACN, RDM and Martin P3; DMX modes of 1, 3, 4, 10, 27 and 243 channels
• Dimensions (excl. bracket): 288 x 288 x 161 mm (11.3 x 11.3 x 6.3 in)
• Weight: 9.32 kg (20.5 lbs) with bracket; 7.65 kg (16.9 lbs) without
