MAR-90250405HU - MAC Aura Raven XIP in SiP

Overview
The MAC Aura Raven XIP is Martin's flagship Aura wash: a 37 x 40 W RGBL engine behind a 343 mm dark front lens, with 234 pixelated RGB aura LEDs. It is IP54 weatherproof for indoor and outdoor use. It ships in a cardboard carton with a SiP foam insert, Martin's transport packaging that wraps and protects the fixture and slots into Martin's flightcase for 2 x MAC Aura Raven XIP (MAR-91515064) (flightcase sold separately).

Best for
Large concerts, festivals, broadcast and touring shows, indoors or outdoors, that need a high-output wash with a pixel backlight.

Highlights

• 27,000 lm fixture output from an RGBL (red, green, blue, lime) LED engine
• 234 individually controllable RGB LEDs for the Aura backlight effect
• Belt-driven, silent zoom (1:5.3) with a 343 mm front lens
• XIP smart weatherproofing, IP54
• Universal Connect Module slot for third-party wireless; yoke handles for transport

Key Specs

• Light source: 37 x 40 W RGBL LEDs plus 234 x 0.3 W RGB Aura LEDs
• Output: 27,000 lm; 1,900,000 cd peak
• CCT: 2,000-12,850 K; CRI 82 or higher
• Control: DMX, RDM, Art-Net, sACN, Martin P3
• Power: 1,120 W max, 100-240 V AC
• IP rating: IP54
• Weight: 28.8 kg (63.5 lbs)
