PRA501 - Proteus Atlas - 500W SSPC Beam FX Fixture, IP66

Overview
The Elation Proteus Atlas is an IP66-rated beam fixture built around a 500W laser-pumped phosphor light engine and a 320mm front lens. It delivers 1,000,000 lux at 20 meters for large-scale productions and permanent outdoor installations.

Best for
Large-scale productions and permanent outdoor installations that need a long-throw, searchlight-style beam.

Highlights

• 1,000,000 lux at 20 m (66 ft) with a 0.6° to 8.5° beam angle
• Full CMY color mixing plus a 25-position color wheel
• Two gobo wheels, dual frost, and 2x3 prisms on dual planes
• SkyMotion standalone synchronization for searchlight-style effects

Key Specs

• Light source: 500W laser-pumped phosphor engine, 9000K, CRI 70
• Lamp life: 12,000 hours
• DMX modes: 30 or 41 channels
• Pan/Tilt: 360°/540° pan, 250° tilt
• Dimensions: 14.6 x 20 x 31.5 in (370 x 508 x 800 mm)
• Weight: 124.1 lbs (56.3 kg)
• Power: AC 100-240V, 700W max
• Rating: IP66
