Data Stream 8

Overview
The Data Stream 8 is a rack-mountable DMX splitter that distributes and boosts DMX signals from two inputs to eight outputs.

Best for
Touring rigs, theatres and installs that need to split one or two DMX lines to multiple fixture runs.

Highlights

• Up to 8 outputs from dual inputs
• Both inputs can be used simultaneously and sent to any output
• Master 3-position switch routes input A or B to all outputs
• Individual 2-position switches select the input for each output
• Optically isolated outputs protect against shorts

Key Specs

• DMX connectors: 3-pin XLR
• Rackmount: 1U
• Input voltage: 100-240 VAC, 50/60 Hz (auto-ranging)
• Power consumption: 2 W
• Dimensions: 19 x 5.2 x 1.7 in (483 x 132 x 44 mm)
• Weight: 4.6 lb (2.1 kg)
